Double Rotor Rubber Strainer Extruding Machine with Hydraulic Head

Brand Name : SFC

Model Number : XJL-150

Certification : CE, ISO

Place of Origin : China

MOQ : 1set

Price : US$15,000.00-20,000.00

Payment Terms : L/C,T/T

Supply Ability : 50set/month

Delivery Time : 25-35days

Packaging Details : Safety Wood or Plywood Crates Packing

Contact Now

Two Rotor Hot Feed Rubber Strainer Extruding Machine

Key Specifications

Screw diameter: 150mm

Screw Length-diameter ratio: 5:1

Screw model: Double headed isometric such deep

Applications

  • Straining natural or reclaimed rubber materials
  • Straining vamp glue and inner tire compound

Key Features

  • Double thread screw with equal pitch and depth
  • Single head or cutter head with hydraulic tightening
  • Jacketed barrel for effective rubber cooling
  • Smooth operation with high output capacity
  • Automatic die-head opening system during power cutoff

Machine Structure

The rubber strainer consists of end, body, screw, reducer, coupling, motor, hydraulic head, base, water (steam) pipe and cabinet. The body features grooves between body and bush for steam or cooling water circulation, with replaceable bush components. A square feed hopper at the rear allows material to be pressed through the screen by screw rotation. The quick-lock bayonet type gear ring with hydraulic opening ensures efficient screen replacement for optimal output and quality.

Technical Specifications

Model XJL-150 XJL-200 XJL-250
Screw Diameter (mm) 150 200 250
Length: Diameter 1:5.14 4.5:1 4:1
Screw Speed (r/min) 53 45 40
Motor Power 37 55 110
Steam Pressure (MPa) 0.6-0.8 0.6-0.8 0.6-0.8
Cooling Water Pressure (MPa) 0.2 0.2 0.2
Capacity (kg/h) 450 900 1800
About Weight (T) ~4.5 ~8 ~9
Double Rotor Rubber Strainer Extruding Machine with Hydraulic Head

Frequently Asked Questions

  • Delivery time? Custom-designed machines require 25-35 days from engineering to production completion.
  • Quality control? Comprehensive quality control throughout production with full assembly and testing before shipment.
  • Quality guarantee? One-year warranty using world-famous brand components for reliable performance.
  • Overseas installation? Available with technical support; small machines 2-3 days, large plants about 30 days.
  • Order accuracy? Guaranteed delivery of confirmed specifications with company culture focused on innovation, quality, and integrity.
  • Factory location? Qingdao City, Shandong province, China, with airport pickup service available.
Double Rotor Rubber Strainer Extruding Machine with Hydraulic Head

Packaging & Shipping

Equipment is painted and wrapped with stretch film to protect surfaces. Custom wooden packaging available with shockproof materials for key components like electronic control boxes. Our team of 15 engineers and 108 skilled workers ensures timely delivery, supported by long-term cooperation with COSCO for reliable port arrivals. Our products have been exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka and many other countries.

Double Rotor Rubber Strainer Extruding Machine with Hydraulic Head

Welcome to visit our factory!
