Lab Mixing Mill, Open Lab Mixing Mill (XK-160)
1. FunctionThe open lab mixing mill is suitable for the mixing and kneading rubber, synthetic rubber, hot melt adhesive, EVA, chemical medicine, ensure the dispersion of raw material and used for small test or small production.
| Roll Diameter |
160mm |
| Roll Working Length |
320mm |
| Roll Hardness |
50-60HRC |
| Front Roll Linear Speed |
8.95m/min |
| Ratio before and after roll |
1: 1.35 |
| Roll Range |
0--4.5 mm |
| Minimum thickness of the tablets |
0.3mm |
2. Construction Features(1) Labor mixing mill is designed for rubber the experimental precision machine, mainly consist of roller, rack, motor, reducer, security system, electric control system components.
(2) The rollers is using LTG-H chilled alloy cast iron material which surface hardness is HS68-72, long service life and internal-pass cooling water or steam. Roller temperature can be controlled to within ±2 degrees.
(3) In front and rear of the machine are equipped with 4 emergency stopping buttons and also in the mill base is equipped a Kick-style stop switch.
(4) With stock pan.
About us:1. 20 years on rubber machine manufacturing and exporting.
2. Delivery within 30 days.
3. Safety wood or plywood crates packing.
4. Full transportation insurance.
5. Sell to 126 countries on 6 continents.
6. One-stop rubber machinery solution in Shun Cheong.
7. Customers can choose according to their needs.
8. The new design concept, strong technical force and advanced manufacturing processes of the company ensure that each rubber vulcanizing press can be manufactured to meet customer's individual requests.
Test Before DeliveryIn order to save time and cost for customers, we produced open lab mixing mill at the factory wires between the motor and the control cabinet already connected, the customer's only need to connect the wires to the outside the control cabinet. After lab mixing mill complete installation will have the load test 4-6 hours to reduce debugging time and cost.
PackagingEquipment painting completed before delivery, and then wrapped with stretch film, avoid rubbing the paint off the surface, wooden packaging can be customized, key parts, such as electronic control box, will be wrapped by shockproof packaging materials, and then packed in wooden cases.
In addition, our rubber vulcanizing press have exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonisia, Australia, Sri Lanka and many other countries.
If you interested in our products mentioned above. Kindly let us know by return email. Then I will supply you with further information.
Welcome to visit our factory!
