Fully Automatic 200 Ton Rubber Tiles Vulcanizing Presswith With PLC Control
Product instruction
This hydraulic vulcanizing press is specially designed for producing rubber floor tiles from rubber granules (waste tire crumb). Under high temperature and high pressure, rubber material inside molds completes vulcanization and molding. It is widely used to manufacture anti-slip rubber tiles for playgrounds, gyms, parks and walkways. Multi-layer platens are optional to improve production capacity. Stable pressure & precise temperature control guarantee uniform tile density and surface quality.
Product picture
Technical data
|
Model
|
Total Pressure
(MN)
|
Daylight
(mm)
|
Working Layer
|
Piston Stroke
(mm)
|
Overall Dimension
(L×W×H)(mm)
|
|
XLB-350*350*2
|
0.25
|
125
|
2
|
250
|
1200*580*1200
|
|
XLB-400*400*2
|
0.50
|
125
|
2
|
250
|
1400*500*1400
|
|
XLB-600*600*2
|
1.00
|
125
|
2
|
250
|
1880*820*1680
|
|
XLB-750*850*4
|
1.60
|
125
|
4
|
500
|
1730*930*2460
|
|
XLB-900*900*2
|
2.50
|
200
|
2
|
400
|
2345*960*1385
|
|
XLB-1200*1200*1
|
3.15
|
300
|
1
|
300
|
2800*1300*2300
|
|
XLB-1300*2000*1
|
5.60
|
400
|
1
|
400
|
2000*1860*2500
|
|
XLB-1500*1500*1
|
8.00
|
800
|
1
|
800
|
2200*2200*4300
|
|
XLB-1500*2500*1
|
15.00
|
400
|
1
|
400
|
3000*2500*3300
|
|
XLB-2000*2000*1
|
20.00
|
400
|
1
|
400
|
3600*3000*3300
|
FAQ
1.Q: What product can this vulcanizing press produce?
A: It is specially used to make various rubber floor tiles.
2.Q: What raw materials are suitable for the machine?
A: It adopts waste tire rubber granules mixed with binder as raw materials.
3.Q: How does the machine form rubber tiles?
A: Under hydraulic pressure, constant temperature heating and vulcanization, materials are cross-linked and molded.
4.Q: Can we choose multi-layer heating platens?
A: Yes, multi-layer platens are optional to improve production output.
5.Q: Where are rubber tiles widely applied?
A: They are used in playgrounds, gyms, parks and outdoor walkways.
Features
The machine is equipped with functions including quick closing via automatic button (quick closing speed: 25 mm/s), slow closing, automatic air venting, automatic pressure compensation, automatic constant temperature with adjustable temperature, vulcanization timing, alarm upon completion, automatic mold opening, as well as automatic forward and backward push-pull turnover plate (fast-slow-stop).
Company instruction
Qingdao Shun Cheong Rubber Machinery Manufacturing Co,LTD is located in Qingdao west coast new economic distrect,witch is a high-tech enterprise “specializing and New “ ENterprise,Nation”High-tech”Enterprise,etc. has been achieved,trademark “顺富昌” registered, and has passed ISO9001:2015 quality system certification , Swiss SGS certification and CE export certication . All the machines are designed with 3D software and are not only sold all over the country ,but also exported to the United States ,Britain ,Russia , the Netherlands , Thailang ,Malaysia , Indonesia , Chile , Mexico , Uzbekistan , France and many other countries and regions .
The main products of our company including new banbury mixer , rubber mixing mill ,vulcanizing press , rubber calender , batch of cooler , rubber kneader , forced feeding straining extruder ,new waste tire recycling line , reclaimed rubber equipment etc . , and can design and manufacture various special rubber machinery according to customer requirements.
Certificates
Our Services
♦ Our engineers can design target machines for customers and send them the drawing to confirm. We are always on the side of saving your cost.
♦ In the process of production, we will take photos and send to customers for their track the progress.
♦ Documents such as packing list, commercial invoice, and bill of lading etc. will be sent after the delivery.
♦ We could supply free English foundation DWG, installation drawing, user guide, maintenance manual and part drawing.
♦ We supply overseas engineer service and help to train your workers to operate the machine.
