Automatic C-Type Tire Tread Press Machine / Rubber Vulcanizing Press
Product Overview
Tire Tread Rubber Vulcanizing Press Machine | Tire Tread Vulcanizer for Recycling Plant
Key Features
- 4 dual-action cylinders with movable beam for quick opening/closing, reducing electricity consumption
- Pneumatic rotating mechanism for multi-step deflation
- Automatic mold forward/backward operation
- Squared axis cantilever hanging heating platen for rapid feeding/discharging
- PLC controlled system
- Unit area pressure no less than 45kg/cm² for optimal tire-surface density
- Multiple options for layer number and tables
- Hydraulic pressure components and electrical equipment from imported or local famous brands
Technical Specifications
| Model |
XLB-3400*300X5 |
| Total Pressure |
4.20MN |
| Heating Plate Size |
3400*300X60(mm) |
| Unit Area Pressure |
4.1Mpa |
| Daylight |
200mm |
| Working Layer No. |
4 |
| Piston Diameter |
285mm |
| Piston Material |
Alloy Chilled Cast Iron |
| Cylinder No. |
4 |
| Cylinder Material |
Ductile Casting-QT500 |
| Piston Stroke |
800mm |
| Working Hydraulic Pressure |
16.47Mpa |
| Plate Heating Mode |
Steam/Oil/Electricity |
| Max. Heating Temperature |
220ºC |
| Press Structure |
Single C Type |
| Control System |
PLC Automatic (Mitsubishi) |
| Motor Power |
15KW |
| Gross Weight |
About 18000KG |
Note: Machine warranty: 12 months since normal working in buyer's factory. Test Procedure: When production is finished, the press will keep pressure up to 4.85MN for 24 hours.
Company Profile
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd is located in Kangting Road No. 1, Huangdao New District, Qingdao City. We are a specializing in the production of rubber machinery of high and new technology backbone enterprises. The company passed the ISO9001:2015 quality management system certification, the European Union CE certification and Switzerland SGS certification.
Industry Coverage
Company's products mainly cover the following industries: tire manufacturing, rubber conveyor belt production, all kinds of rubber products, tires refurbished manufacturing, waste tire recycling.
Main Equipment
The main equipment includes: Rubber Kneader, Rubber Mixing Machine, Rubber Vulcanizing Press, Batch Off Cooler, Rubber Calender, Waste Tire Crusher, Rubber Extruder, Rubber Strainer, etc.
Global Reach
Company's products are exported to Britain, Switzerland, USA, Germany, Brazil, Singapore, Malaysia, India, Russia, Ukraine, Uzbekistan, Kazakhstan and more than 50 countries and regions, winning praise and long-term cooperation from domestic and foreign customers.
Quality Commitment
- Every part passes strict quality inspection before storage
- All products undergo overload trial running before shipment
- Complete technical support provided for all products
- 3-year warranty for main parts, 1-year warranty for wearing parts
- Comprehensive after-sales service including remote support and on-site repair if needed
Our Services
- Custom machine design with drawings for customer confirmation
- Production progress photos and updates
- Complete documentation including packing list, commercial invoice, and bill of lading
- Free technical documentation (DWG, installation drawings, user guides, maintenance manuals)
- Overseas engineer service and operator training
Frequently Asked Questions
1. What does your factory do regarding quality control?
We pay much more importance to quality control from the very beginning to the end of production. Every machine will be fully assembled and carefully tested before shipment.
2. What's the machine quality guarantee?
Quality guarantee time is one year. We choose world famous brand components to keep our machine in perfect working condition.
3. Are you able to give installation and commissioning overseas? How long time will it take?
Yes, we can supply overseas service and technical support but customer needs to pay for the cost of the installation. Small machine usually takes within 2-3 days. Big production line usually takes about 30 days.
4. How can I trust you to deliver the right machine as I ordered?
We will absolutely deliver a good quality machine as we discussed and confirmed in the order. The core of our company culture is innovation, quality, integrity and efficiency.
5. How can we go to your side?
We are located in Qingdao City, Shandong province, China. The name of airport is Qingdao Jiaodong Airport. We will pick up you at the airport.
